Warman pump
M, AH, HH series slurry pump
Brief Introduction
M, AH, HH series centrifugal slurry pumps adopt replaceable wear-resistant metal or rubber liners. The impellers are made of wear-resistant metal or rubber. The pumps are mainly used to pump high-hardness, strong-corrosion and high-concentration liquids that contain suspended solid particles, such as finished ores, refuse ores, ashes, cinders, cements, mud, mineral stones etc.
Meaning of pump model
Pump 4/3 A -AH (or M、HH)
AH (or M、HH)----Pump type
A----Frame type
3--- Outlet diameter (inch)
4----Inlet diameter (inch)
Main Technical Parameters
Model | Allowable max. power of motor Kw | Material | Clear water performance | Impeller | |||||||
liner | Impeller | Clear water performance | Head m | Speed r/min | Max eff % | NPSH m | Qty | Dia. mm | |||
m³/h | l/h | ||||||||||
2/1½B-AH | 15 | M | M | 32.4-72 | 9-20 | 6-58 | 1200-3200 | 45 | 3.5-8 | 5 | 184 |
RU | RU | 25.2-54 | 7-15 | 5.5-41 | 1000-2600 | 50 | 2.5-5 | 178 | |||
3/2C-AH | 30 | M | M | 39.6-86.4 | 11-24 | 12-64 | 1300-2700 | 55 | 4-6 | 5 | 214 |
RU | RU | 36-75.6 | 10-21 | 13-39 | 1300-2100 | 2-4 | 213 | ||||
4/3C-AH | 30 | RU | RU | 79.2-180 | 22-50 | 5-34.5 | 800-1800 | 59 | 3-5 | 5 | 245 |
4/3D-AH | 60 | ||||||||||
4/3C-AH | 30 | M | M | 97.2-194.4 | 27-54 | 9-53 | 1000-2200 | 55 | 3 | 240 | |
4/3D-AH | 60 | ||||||||||
4/3E-HH | 120 | M | M | 126-252 | 35-70 | 12-97 | 600-1400 | 50 | 2-5 | 5 | 508 |
6/4D-AH | 60 | M | M | 180-396 | 50-110 | 7-61 | 600-1600 | 55 | 3-8 | 4 | 372 |
6/4E-AH | 120 | ||||||||||
6/4D-AH | 60 | RU | RU | 144-324 | 40-90 | 12-45 | 800-1350 | 65 | 3-5 | 5 | 365 |
6/4E-AH | 120 | ||||||||||
8/6E-AH | 120 | M | M | 360-828 | 100-230 | 10-61 | 500-1140 | 72 | 2-9 | 5 | 510 |
8/6R-AH | 300 | ||||||||||
8/6E-AH | 120 | RU | RU | 360-828 | 100-230 | 7-52 | 400-1000 | 70 | 2.5-6 | 4 | 536 |
8/6R-AH | 300 | ||||||||||
8/6T-HH | 1200 | M | M | 576-1152 | 160-320 | 32-95 | 450-725 | 65 | 6-10 | 5 | 965 |
Application:
Wolman slurry pump
Sand slurry pump
