Belt conveyor
Description
Our belt conveyor has a feature of large capacity, simplified construction, easy maintenance, standardized components. It is widely used in mining, metallurgy, chemical and other production sectors. It is used to transport relax material and member goods, according to the request of transport technology. It can be used in single, multiple or combined with other equipment to from horizontal or incline transportation system to satisfy different production line arrangement needs.
Note:
1. The conveying quantity is worked out by the following conditions: material density is between 1.0t/m3-1.6t/m3; conveyor obliquity is less than 18o and the material stockpile angle is 30o.
2. Density of material is less than 2.5t/m3.
3. The conveying length is not restricted to the form; different length can be manufactured according to customers' demands.
Main Technical Parameters
Belt Width (mm) | Conveying Length (m) Power (Kw) | Conveying Speed(m/s) | Conveying Amount (t/h) | ||
500 | ≤12 3 | 20-30 4-5.5 | 20-30 5.5-7.5 | 1.3-1.6 | 78-191 |
650 | ≤12 4 | 12-20 5.5 | 20-30 7.5-11 | 1.3-1.6 | 131-323 |
800 | ≤6 4 | 6-15 5.5 | 15-30 7.5-15 | 1.3-1.6 | 278-546 |
1000 | ≤10 5.5 | 10-20 7.5-11 | 20-40 11-12 | 1.3-2.0 | 435-853 |
1200 | ≤10 7.5 | 10-20 11 | 20-40 15-30 | 1.3-2.0 | 655-1284 |
Also can process mobile type belt conveyor:
Mobile conveyor
Gravel conveyor belt
Application:
Manganese plant whole line machine
Chrome wash plant
